U-shape connector of bed shelf
The U-shaped connector is a 3mm iron component for the raising and lowering rocker-arm connection on a medical transfer stretcher. Match the U-section and fastening interface to the stretcher mechanism before ordering.
U-shape connector of bed shelf — YY-000055
The U-shaped connector is a 3mm iron component for the raising and lowering rocker-arm connection on a medical transfer stretcher. Match the U-section and fastening interface to the stretcher mechanism before ordering.
Product specifications
| Parameter | Details |
| Model No. | YY-000055 |
| Material | Iron |
| Product Dimension | Customizable |
| Color Options | Powder coating color according to customer requirements |
| MOQ | 100 pcs |
| Packaging | Wooden box or wooden frame, depending on the quantity of products |
| Gross Weight | About 0.8KG per unit |
| Lead Time | 10–15 working days |
| Warranty | 1 year Technical guidance |
Fit checks for U-shape connector of bed shelf
- U-section width, mating arm dimensions and connection-hole pattern.
- Connector mounting position and fastening arrangement.
- Rocker-arm travel and clearance within the stretcher assembly.
For a drawing-based quotation, send the required quantity and a dimensioned part or assembly drawing. Confirm the material grade, tolerances, surface finish and mating interfaces for the ordered version.
U-shape connector of bed shelf: ordering questions
How is the connector matched to a transfer stretcher?
Compare the connector drawing with the required stretcher rocker-arm mechanism. Confirm the U-section, fastening interfaces and installed orientation for your order.
What minimum quantity and lead time are listed?
The current specification table lists an MOQ of 100 pcs and a lead time of 10–15 working days. Confirm these terms for the required drawing, finish and quantity in the quotation.
What information should accompany a replacement enquiry?
Identify YY-000055 and include the existing component’s dimensions or drawing, its installation position and details of the mating parts. A photograph can help identify the version, but does not replace the fit dimensions.
Product documentation
For your procurement file, request the current document copies and confirm their scope against the ordered model.
Request a component quotation
Send the drawing, quantity and required finish for U-shape connector of bed shelf through the Chat button or email [email protected].
Browse related hospital bed metal parts and Emergency Transfer Stretcher to identify the corresponding assembly category.
