Connecting small ear (1) of bed panel — YY-00024
Connecting small ear (1) is made from 3mm iron material. It is welded around the hospital bed frame and forms part of the bed-panel support arrangement as the panel lowers. Confirm the contact position and joint geometry using the panel and frame drawing.
Product specifications
| Parameter | Details |
| Model No. | YY-00024 |
| Material | Iron |
| Product Dimension | Customizable |
| Color Options | Powder coating color according to customer requirements |
| MOQ | 100 pcs |
| Packaging | Wooden box or wooden frame, depending on the quantity of products |
| Gross Weight | About 0.2KG per unit |
| Lead Time | 10–15 working days |
| Warranty | 1 year Technical guidance |
Fit checks for Connecting small ear (1) of bed panel
- Frame welding location and ear orientation.
- Panel contact position and connection geometry.
- Clearance throughout the bed-panel movement.
For a drawing-based quotation, send the required quantity and a dimensioned part or assembly drawing. Confirm the material grade, tolerances, surface finish and mating interfaces for the ordered version.
Connecting small ear (1) of bed panel: ordering questions
How should the welding position be specified?
Provide a frame and panel assembly drawing showing the ear's position and orientation. The contact arrangement should be checked with the intended panel movement before production.
What minimum quantity and lead time are listed?
The current specification table lists an MOQ of 100 pcs and a lead time of 10–15 working days. Confirm these terms for the required drawing, finish and quantity in the quotation.
What information should accompany a replacement enquiry?
Identify YY-00024 and include the existing component’s dimensions or drawing, its installation position and details of the mating parts. A photograph can help identify the version, but does not replace the fit dimensions.
Product documentation
For your procurement file, request the current document copies and confirm their scope against the ordered model.
Request a component quotation
Send the drawing, quantity and required finish for Connecting small ear (1) of bed panel through the Chat button or email [email protected].
